Metallurgical Image Analysis Software

We are a leading Manufacturer, Exporter & Supplier of Metallurgical Image Analysis Software.

Metallurgical Analysis Software

Metallurgical Analysis Software
This software can be used in steel plants, metal forging industry, oil & gas industry ,material science,mineralogy - metal and metal strength analysis cement (klincker) quality control and where ever metallurgical microscope are used in . This package is very useful educational institutions and all material science technocrats and metallurgists. metallography tools grain size decarbization coating thickness phase nodularity porosity inclusion particle measurement inclusion din hardness testing.

It Has two Main tool bars-

Measurement Tool-Length, Width, Angle, Radius, Area, Perimeter, Calibration etc

Metallography Tools-

  • Grain Size
  • Percentage and distribution of phase
  • Decarbization
  • Coating Thickness
  • Decarb Depth
  • Nodularity in SG iron
  • Porosity
  • Inclusion rating in steel
  • Particle Measurement
  • Hardness Testing
  • Welding Penetration

Send Enquiry

Image Analysis Software

Image Analysis Software

Knowing the precise demands of clients, we are engaged in offering our clients a wide range of CCD Image Processing Systems. These are specially designed and developed following international industry standards and are widely acclaimed for their sturdy construction and accuracy in result. CCD Image Processing Systems offered by us are very easy to operate and are ideal for various factories, laboratories and other allied areas.


Feature & Use:


  • The CCD image processing system can finish the process automatically: measurement of the diagonal length of indentation, hardness value display, testing data and image saving, etc
  • Proceed hardness testing on 20 test points at one time (preset the distance between test points at will), and save the testing results as one group
  • Inquire the saved data and image at any time
  • Customer may adjust the accuracy of the measured hardness value at any time according to the calibration of Hardness Tester
  • It is available to preset the upper and lower limit of hardness value, the testing result can be inspected whether it is qualified automatically
  • Converting between various hardness scales and tensile strength


Standard accessories


  • CCD camera
  • Image processing software
  • Image card


Send Enquiry
